| Discontinued | No |
|---|
| Additional Specifications: | |
|---|
| Storage Capacity (cu. ft.) |
23 |
| Door |
Single Swing Solid Right Hinged Door |
| Shelves |
Five adjustable shelves with guard rail on back |
| Drawers |
Optional pull-out drawers available |
| Mounting and Installation |
4 preinstalled swivel casters, front casters locking |
| Interior lighting |
Shielded, switched LED lighting, full coverage, balanced spectrum |
| Airflow Management |
Forced Air technology, patent pending |
| External probe access |
Rear wall port (3/4") dia. |
| Insulation |
Cabinet is foamed-in-place with EPA compliant high density urethane foam |
| Exterior materials |
White powder coated steel |
| Access control |
Key Lock |
| General warranty |
Two (2) years parts and labor warranty |
| Compressor warranty |
Seven (7) years compressor warranty |
| Product Weight (lbs) |
274 |
| Shipping Weight (lbs) |
33 |
| Rated Amperage |
3 Amps |
| Power Plug/Power Cord |
NEMA 5-15 plug |
| Facility Electrical Requirement |
110-120V AC: 15 A (minimum) |
| Agency Listing and Certification |
ETL, C-ETL listed and certified to UL471 standard, hydrocarbon refrigerant safety, Energy Star Certified |
| Uniformity¹ (Cabinet air) |
±0.6 |
| Stability² (Cabinet air) |
±0.6 |
| Maximum temperature variation (Cabinet air) |
±0.9 |
| Stability² (Simulator ballast) |
Non-applicable |
| Stability² (Simulator bag) |
Non-applicable |
| Temperature Rise after Short Door Openings |
Non-applicable |
| Recovery after Short Door Openings |
Non-applicable |
| Energy Consumption (KWh/day) |
1.15 |
| Average Heat Rejection (BTU/hr) |
320 |
| Noise Pressure Level (dBA) |
35 or less installed |
| Pull down time to nominal operating temp |
55 min |
| Compressor |
Hermetic, variable speed (VSC). Rated speed range: 1300-4000 rpm |
| Refrigerant |
EPA SNAP compliant, R600a |
| Condenser |
Anti-fouling tube and grid design, ultra-quiet multi-speed fan |
| Evaporator |
Fin and tube design, high efficiency fan |
| Defrost |
Cycle optimized, zero energy |
| Controller Technology |
Proportional Integral Derivative (PID) microprocessor with LCD display |
| Battery Backup |
24V high-capacity battery, controller, all alarms active, temperature monitoring DAQ and event logging active on battery backup |
| Display Technology |
Non-applicable |
| Digital Communication |
RS-485 (MODBUS) |
| Data Transfer |
USB port for data transfer and software updates |
| Chart Recorder |
Non-applicable |
| Adjustable Temperture Range |
1°C to 10°C |
| External Alarm Connection |
State switching remote alarm contacts |
| Alarms |
Alarm logging (last 100 entries) with Visual and audible indicators: Power failure, Temperature sensor failure, Battery voltage monitor and replacement, High / Low temperature, Door ajar. |
| Controller Probe |
Bottle with glass bead thermal media |
| Disclaimers |
Performance data acquired at 22°C ambient, 4°C nominal set point in an empty cabinet with shelves using air probes, during stabilized steady state operation and a DAQ sampling rate of one measurement every 10 seconds1 - Uniformity is defined as the maximum variance in temperature across all probes at any point in time over the testing period2 - Stability is defined as the maximum variance in temperature experienced by any single probe over the testing period3 - Data per Energy Star test results or equivalent testing and calculation. Heat rejection based on daily averages, not continuous operation. Performance exceeds Energy Star requirements4 - Charts serve as representations of the product family, and actual performance may vary slightly |
| Dimensions |
Exterior: 26 7/8" (W) x 36 3/8" (D) x 81 1/2" (H)
Interior: 22" (W) x 25" (D) x 52 1/4" (H)
|
| Unit of Measure (UOM) | Each |
|---|
