GX Solutions Pass-Thru blood bank refrigerators provide a professional medical-grade refrigerator with a digital microprocessor temperature controller that includes basic alarms and temperature display. The HBR226-GX is a two-door Pass-Thru Blood Bank Refrigerator (one door on each side) that safely stores blood products at 4?C and allows easy transfer of product between spaces. Essential alarm functionality provides continuous monitoring. Innovative OptiCool technology offers energy savings, quiet operation, and low heat output, in addition to the excellent temperature uniformity and recovery that are critical for blood storage. GX Solutions Pass-Thru refrigerators have undergone extensive use case testing to ensure they meet rigorous performance requirements, including multiple and extended door openings.
Features:
Designed to safely store blood and blood components within an exceptional temperature-controlled environment
OptiCool technology pairs a variable capacity compressor (VCC) and natural hydrocarbon refrigerants to ensure optimal temperature uniformity, recovery, and stability, efficiently manage energy consumption and meet evolving environmental regulations
Optimized temperature uniformity, recovery and stability create best environment for blood storage
U.S. Environmental Protection Agency SNAP (Significant New Alternatives Policy) compliant refrigerants
Quiet operation creates fewer distractions and better working environment
Digital microprocessor temperature controller with built-in alarms, includes min/max display and reset
Audible and visual alarms include power failure, high and low temperature alarms, door ajar, condenser temperature, and low battery
Cabinet built with high-quality construction meets or exceeds performance standards required by the medical and scientific industries
Adjustable, liquid-tight drawers for containment of spills
Rear access port
Insulation: Sustainable, US EPA, and SNAP approved foam
Trim/Skirt Kit Details (sold separately ): Trim kit - side rails 3" x 81.8", top rail 3" x 35", 1 kit per side needed, skirt kit - 2.7" x 29", Clean room side only, Bacteria-resistant powder-coating
Access Port: Top Access Port- for external monitoring probe(s) (0.75" diameter)
Casters: Yes, swivel-locking
Clearance Requirements: Minimum of 8" above the ante-room (control) side of the refrigerator. Clearance above the solid cover on the clean room side may be 0".
Facility Supply Rating
Branch circuit with earth ground, meeting plug/cord ratings as well as local electrical safety codes and requirements
110-120V AC: 15 A (minimum)
220-240V AC: 10 A (minimum)
Power Plug/Power Cord Length
NEMA 5-15 hospital-grade | 115V 60Hz, 8 to 10 ft (2.4-3.0m) Inquire about additional plug/cord options
Certifications/Regulatory Approvals
QPS (Certified to UL and CSA Standards), CE 2797, RoHS
Solid Ballast Simulator Kit for GX Model Refrigerators
Solid Ballast Simulator is a maintenance-free thermal buffering solution designed to replace glycerin bottles. Uses existing wall or ceiling-mounted bracket.
Ventilated Shelf (Pass-Thru)
Full Shelf, Ventilated, White (with hardware). For field installation (for 26 and 58 cu ft Pass-Thru Refrigerators)
Drawer - Horizon w/Hardware, Pass-Thru
Drawer, 2-Way, Liquid-Tight, Stainless Steel (with slides), for Field Installation (for Horizon Series 26 and 58 cu ft Pass-Thru Refrigerators)
