Welch Allyn QS6-ATTD1 Q-Stress Cardiac Stress Version 6

main product photo

Details

Through innovative technologies and smart design, the Welch Allyn QS6-ATTD1 Q-Stress Cardiac Stress Version 6 solves common challenges associated with the successful acquisition and interpretation of cardiac stress testing exams. A few of its most notable features include an impressive 24" touchscreen interface with protocol-driven, pre-defined selections; 12-lead ECG interpretation for adults, adolescents and children; and standards-based HL7 and DICOM bidirectional connectivity. Plus, VERITAS technology offers exceptional accuracy in real-time ST-segment monitoring, arrhythmia detection and resting ECG interpretation - delivering critical data through each stage of the stress test. With a legacy of excellence, the Q-Stress system delivers all of this and more in a smart, user- and patient-focused solution.

Features:

  • Source Consistency Filter designed to remove noise and maintain ECG integrity.
  • Examine historical ECG data throughout the exam with real-time full disclosure.
  • Label, store, print & review events on the fly and include them in the final report.
  • Optional wireless data acquisition increases workspace flexibility.

The unique WAM Wireless Acquisition Module benefits both patients and clinicians:

Equivalent in size and weight to a conventional wired patient cable, the Wireless Acquisition Module provides freedom of movement for the clinician while acquiring electrocardiograms and during cardiac stress testing. With the Wireless Acquisition Module, the electrocardiograph no longer needs to be right at the patient’s bedside; this is particularly advantageous in critical situations or when the patient is in isolation.

  • Dedicated, secure communication links the module to a single ECG/cardiac stress testing system.
  • Full diagnostic-quality ECG with a high-fidelity acquisition sampling rate of 40,000 samples per second per channel—a benefit for accurate pacemaker detection.
  • Elimination of the cable reduces a source of artifact, resulting in high-quality ECG tracings.
  • On/off, 12-lead ECG acquisition and rhythm printing at the bedside with the simple press of a button.

Quote Information

Commercial Procurement Made Easier

New healthcare facility construction, expansion or remodel - we’ve created a streamlined approach to healthcare supply chain for our following customers:

  • Medical facilities (Hospitals, Physician Offices, Long Term Care facilities, etc.)
  • GPO members (Vizient, Premier, Intalere, Healthrust, ROi)
  • Government Agencies (VA, DoD)
  • Educational Institutions (Universities, Schools, etc.)
  • other bulk buyers

How to Request a Quote

Simply search for your desired product(s), and click ‘Chat with Us for GPO Pricing!’ to connect with one of our product specialists. They will note your contact information and any comments/questions about the item or an overall quote, and submit it to an account manager. One of our dedicated account managers will reach out to you with your pricing and to discuss your logistics needs within 12 hours.


CME Makes It Easy

  • 2 million+ products, from over 2000 manufacturers.
  • Contract pricing with all the major GPOs, and volume discounts for bulk orders.
  • We save you time and money by being your most competitive source for all items in your PO/quote, and we’ll even locate those products we don’t carry at the best price.
  • Streamlined, on-time delivery with turn-key white glove service, scheduled for when its best for you.

Quote to Delivery. One Team. One Partner. CME Makes It Easy.

Write a review
In stock
SKU
CESS-747023-00001
MPN
QS6-ATTD1

Includes: Adult and pediatric interpretation; current software CD and user manual CD; AM12Q Wired Acquisition Module with Trigger Module for TTL/analog signal output and TM55 110V Treadmill; Turnkey system with configured CPU and ELO brand capacitive color touchscreen 24" monitor with 1920 x 1080 resolution; US/Canada power cord; Z200+ thermal printer, (includes 2 starter packs of full-grid paper - 8"), Q-Stress premium transport cart with base, keyboard tray, storage shelf, large storage drawer, and side storage pocket; AHA 10 wire, 12-lead lead set.

Hillrom/Welch Allyn is now part of Baxter Healthcare

$39,733.07

GPO, Government & B2B Customers ?

Add to Wish List
Specifications
DiscontinuedNo
Additional Specifications:
  • Product Type: Cardiac Stress Testing System
  • System Dimensions: 24.6" (L) x 22.5" (W) x 62.5" (H)
  • Paper Tray Width: 32.6"
  • Side Shelf and Paper Tray Width: 50"
    • Treadmill Specifications:
    • Overall Dimensions: 46.5" (L) x 80.2" (W) x 29.9" (H)
    • Running Surface Dimensions: 6.3" (L) x 55" (W) x 20" (H)
    • Optional Side Handrails Dimensions: 24" (L) x 40" (W)
    • Treadmill Weight: 352 lbs
  • Operating System: Microsoft Windows 7 Professional 32-bit or 64-bit, or Microsoft Windows 10 Pro 64-bit
    • Protocols:
    • Standard: Bruce, Modified Bruce, Modified Balke, Naughton, USAF/SAM 2.0, USAF/SAM 3.3, Ramped-low, Ramped-medium, Ramped-high, Time-Ramp, and METs Ramp, Astrand (ergometer), pharmacological, and more
    • Custom: Up to 100 Custom Protocols Assorted
  • Front-End Module: AM12Q with AHA 10-Electrode Pinch or Snap Connectors, AM12Q with IEC 10-Electrode Pinch or Snap Connectors, WAM Module for Wireless ECG Acquisition with AHA 10-Electrode Pinch Connectors, WAM Module for Wireless ECG Acquisition with IEC 10-Electrode Pinch Connectors
    • ECG:
    • Lead Groups: Standard (Mason-Likar), Cabrera 12-lead
    • Display Format: 3, 6, 6x2, or 12x1 Channels
    • Performance Standard: IEC 60601-2-25 Gain Accuracy, Frequency Response, CMRR, System Noise, Dynamic Range and Input Impedance
  • Display and Analysis Filters: Source Consistency Filter (SCF), Muscle Artifact, Baseline Wander, 40 Hz Low Pass, Line Frequency
    • Reports:
    • In-Test: 12-Lead, Average Beat Report, 1-Page Write Screen, Continuous Rhythm, Arrhythmia Events
    • Final: Summary, Tabular, Worst Case, Average Beats by Stage or by Minute, In-Test ECG Reports, Trend Graphs and Peak Exercise. Reports can be Viewed, Printed, Saved in PDF format, Emailed or Exported in PDF, XML, and DICOM
    • Custom: Unlimited Customizable Reports
  • Outputs: TTL Pulse and Analog Signals for QRS Detection Synchronization Using any ECG Lead
    • External Device Interfaces:
    • Treadmills: TM 55
    • Ergometers: Compatible with Ergoline and Lode Communication Protocols
    • Blood Pressure Monitors: Suntech Tango+ and Tango M2
    Printers:
    • Thermal: High-Resolution Z200+ with Automatic Feed and Continuous Printing Capability (Requires Additional Network Port)
    • Laser: Optional Compact HP M501DN Laser Printer with High-Quality Print (Recommended)
    • Paper: 8.5" X 11" (Letter) Or 210 mm X 300 mm (A4)
  • Network Interface: Microsoft-Compatible Networking for Storage, Distribution and Email; 100 Mbps Connection or Better is Required
  • Paper: Smart (8.27" X 11.02"), Perforated Z-fold Thermal Cued Paper with Full Grid; 250 Sheets Stored in Paper Tray
  • Export/Communication Protocol/Format: TCP/IP, PDF, XML, HL7, DICOM
  • Remote Technical Service Interface: Remote Service Increases System Uptime Availability and Decreases the User's Requirement to Assist the Troubleshooting Process. Available via Network or Desktop Connections
  • Display: 24" Touchscreen Display
  • Speed Range: 0.8 mph to 9.6 mph (1.3 km/h to 15.4 km/h) in 0.1 mph Increments
  • Incline Range: 0% to 25%, in 0.5% Increments
  • User Weight Capacity: 500 lbs
    • Power:
    • Low Voltage: 100/120 VAC @ 20 A; 50/60 Hz; NEMA 5-20R Non-Locking Receptacle; Single-Phase Dedicated Circuit
    • High Voltage: 200/230 VAC @ 10 A; 50/60 Hz; NEMA 6-15R Non-Locking Receptacle; Single-Phase Dedicated Circuit
  • Package Includes: Cardiac Stress System with Adult and Pediatric Interpretation, Current Software CD and User Manual CD, Wired Acquisition Module with Trigger Module, 110V Treadmill, Turnkey System with Configured CPU, Color Touchscreen 24" Monitor with 1920 X 1080 Resolution, Power Cord, Thermal Printer (Includes 2 Starter Packs of Full-grid Paper - 8"), Premium Transport Cart with Base, Keyboard Tray, Storage Shelf, Large Storage Drawer, and Side Storage Pocket, AHA 10 Wire, 12-lead Lead Set
  • Weight: 270 lbs
  • Quantity: 1/Pack
Unit of Measure (UOM)Each
Choose your Option 1DICOM Enabled with Trigger Module and Touchscreen Monitor
Dimensions62.5" (H) x 24.6" (W) x 22.5" (D)
IncludesAdult and pediatric interpretation; includes current software CD and user manual CD; AM12Q Wired Acquisition Module with Trigger Module for TTL/analog signal output and TM55 110V Treadmill; Turnkey system with configured CPU and ELO brand capacitive color
Warranty13 Months (Parts & Labor)
