Joerns HOY-ELEVATEWSC-S Hoyer Elevate Professional Patient Lift, Sit to Stand, with Scale, Electric Base - 440 lb. capacity

In stock
SKU
CESS-812961-00001
MPN
HOY-ELEVATEWSC-S
Features include: Smart monitor technology, intuitive push pad, angled, removable foot tray.
$9,799.28

The Elevate is an active lift designed to improve the lifting experience for both the caregiver and the patient. It is compact and sturdy with a safe working load of 440 lbs. Included is smart monitor technology that displays actual lifts as well as reminds you to recommended service. This helps drive user compliance and keeps your Elevate in top shape! The Elevate incorporates key intuitive features for caregiver safety. These include a spring-loaded lever to adjust kneepad height as well as a rubber push pad designed to initiate lift movement eliminating initial push forces. The Elevate has been designed with a weigh scale. The weigh scale is seamlessly integrated with a digital display and user friendly controls.

The Elevate is a high-performance active lift designed to improve the lifting experience for both the caregiver and the patient. It is both sturdy and compact with a maximum safe working load of 440 lb / 200 kgs. An optional digital scale allows the caregiver to precisely weigh a patient during the transfer process, saving time and avoiding unnecessary patient disruption.

Features:

  • Smart monitor technology drives user compliance and lift longevity
  • Intuitive push pad assists with initiating movement.
  • One hand adjustable kneepad with infinate settings
  • Angled, removable foot tray
  • Included scale
Removable Foot Rest

The foot rest transforms the lift into a valuable restorative care aid, allowing the patient to fully stand and walk under close supervision.

Powered Leg Adjustment

Powered leg adjustment allows the caregiver to open and close the legs without bending or twisting or use of force.

Adjustable Knee Pad

Contoured, height adjustable knee pad offers high-level comfort and accommodates a range of patient sizes.

Class III Digital Scale

Simple and intuitive controls allow precision weight monitoring during transfer, saving valuable time for caregivers.

Specifications
DiscontinuedNo
Additional Specifications:
  • Product Type: Patient Lift
  • Maximum Overall Dimensions: 43.3" (L) x 65.5" (H)
  • Minimum Overall Dimensions: 41" (L) x 48.4" (H)
  • Legs Open Length: 39.1" (External), 34.3" (Internal)
  • Legs Closed Length: 24.8" (External), 20" (Internal)
  • Maximum Height to Attachment Point: 64.7"
  • Minimum Height to Attachment Point: 39.2"
  • Turning Radius: 48.2"
  • Safe Working Load: 440 lbs
  • Mast, Base and Boom Assembly Weight: 127.3 lbs
  • Power Pack Weight: 6.6 lbs
  • Base Assembly Weight: 40.7 lbs
  • Mast & Boom Assembly (No Battery) Weight: 66 lbs
  • Weight: 136.4 lbs
Unit of Measure (UOM)Each
