Details

Features:

• Ventilation clearance 16" top, 2" back
• Electrical 115 V/60/1 (103 - 132 V) 12 full load amps, Max. fuse 20 amps, dedicated circuit, NEMA 5-20P, 90° hospital-grade plug, 9' (2.7 m) cord
• Door hinges torsion rod self-closing with 90° hold open feature
• 6 swiveling dual wheel casters with toe locks
• (2) energy efficient full length LED lights
• 3rd party probe access soft access port on left side of cabinet
• High and low product temperature alarm (top probe) audible and visual, user programmable set points in C or F
• Probe error alarm audible and visual-product temperature probes, refrigeration and defrost
• Min/max temperature log shows highest and lowest product temperature since last reset occurred
• Information log - graphs or displays temperature data and displays chronological event data (50,000 data points)
• Temperature probe calibration - top probe calibration in 0.1° increments
• Password protection PIN 4 digit password to prevent interface setting/selection changes
• Remote contacts - NO/NC standard, located behind front panel
• Refrigeration cycle with probe error factory set at 2 min on, 6 off
• Refrigeration system integral top-mounted modules with 0.5" hp compressor and air-cooled condenser
• Air circulation system ducted air to each storage level through plenum openings
• Air temperature pull down 27 to 4 C (80 to 39 F) in 30 minutes
• Product simulation bottle temperature pull down 27 to 4 C (80 to 39 F) in 5 h 45 min (to 8 C (46 F) in 1 h 50 min)
• BTU/hr normal heat rejection, includes duty cycle (75 F ambient) 1480 BTU/hr (434 W)
• BTU/hr maximum (total) heat rejection, continuous operation (75 F ambient) 5240 BTU/hr (1536 W)

• Modular refrigeration system with microprocessor controller provides a ±1 C (1.8 F) performance throughout
• Industry-exclusive center plenum air distribution delivers cold air to both sides at six different levels
• Frost-free and auto-evaporating condensate

• 7" LCD capacitive touchscreen digital temperature display available in user-programmable C or F
• Integral event and data logging with easy downloading via convenient USB port

• Audible and visual high/low temperature, door open, power failure, low battery alarms
• Dry contacts for remote alarming

• Full stainless steel interior and exterior provide resistance to rust and corrosion
• Quick-connect RTD product temperature probe easily accessible inside storage cabinet
• Dished stainless floor contains spills for easy clean up
• Heavy-duty dual casters roll easily and lock securely
• 2.75" of CFC-free foam insulation throughout
• 8 heavy-duty epoxy-coated shelves standard (4 per side)

• Dual-pane glass door or solid stainless door with ADA compliant full length locking handle
• Energy efficient low-E glass coating to reduce energy loss by 30 - 50% compared to non-coated glass
• Glass remains condensation-free to 27 C (80 F) at 60% RH and eliminates need for heated doors in most applications
• Self-closing hinges lock open at 90 degrees for easy product loading

• Full length LED light bars illuminate all shelves
• Instant-on LEDs eliminate delay of fluorescent lights and deliver longer life
• Energy-efficient LEDs allow products to be placed next to lights
• Auto on with door opening; ON/OFF front panel switch

• Additional shelves, set of 2 (item 00927269)
• Quick-connect replacement RTD temperature probe with ISO 17025 certificate of traceable calibration (item 01140458)
• Replacement high-side refrigeration module (complete condensing unit) (item 01147891)
• Digital data logger kit (item 01057561)
• Pyxis compatible door bracket, available on one outside handled door of right or left hinged models only (item 00927202)
• medDISPENSE compatible door bracket, available on one outside handled door of right or left hinged models only (item 00978296)
• Glycerine, 16 oz (item 00959296)
• Additional key (item 00945436) for glass door
• Wall bracket kit, seismic anchoring (item 00927194)
