Schiller Tranquility II Touchscreen Patient Monitor with Gas Analyzer

Hausmann Weight Boxes feature two hand grip slots on each side for alternative hand placement during exercises. All weight boxes feature a 0.75 in plywood core covered with a high pressure oak laminate protective finish, as well as durable dowel construction for unmatched longevity. All weight boxes feature on removable metal 1 in diameter weight pin with a locking collar to accommodate optional 8952 disc weights - See accessories below. Hausmann Weight Boxes are rated to handle a 75 lb capacity. Hausmann Weight Boxes are available in four styles; a Carry-All Weight Box, a Tool Kit Weight Box, a Stockroom Crate Weight Box, and a Packing Carton Weight Box.

The Tranquility II features ECG, ISA sidestream gas analysis, NIBP, SPO2, temperature, and respiration monitoring, all displayed on a 12.1 inch touch screen LCD. The monitor is adaptable to a variety of situations by allowing the user to switch between 4, 6, and 8 waveforms displayed simultaneously with a 72 hour trend time. Other features include drug dose calculations, S-T Segment analysis, arrhythmia analysis, and customizable alarms. The patient monitor is also available with or without a built-in printer.

With a weight of 11 lbs, built-in handle, and 1 hour of battery life, the Tranquility II can easily follow a patient from room to room and continue to operate during power disruptions. Suitable for neonatal, pediatric, and adult applications, the Tranquility II is available with a range of accessories to meet the needs of your patients. Options for rolling stands, wall mounts, ETCO2, invasive blood pressure, and other advanced features are also available (See accessories below for details).

Tranquility II patient monitors are proudly made in the USA.

• Includes ISA Sidestream Gas Analysis
• 12.1 inch touchscreen
• Large font display with 4, 6 & 8 waveforms shown
• Networkable with central monitoring system via a wireless or wired network
• ISA Sidestream Gas Analyzer
• 5-lead ECG cable and standard AAMI line for connection
• Automatic oscillating measurement non-invasive blood pressure
• RA-LL impedance respiration measurement
• Anti-Motion SPO2 Measurement
• S-T Segment & 72 hours trend data analysis
• Compact design for mobile monitoring
• Built-in battery with 1 hour operating time
• Integrated 2-channel thermal printer (0-750000ETP-401 Only)

Measurement Parameters Include:

• Multi-Lead ECG monitoring
• Non-Invasive Blood Pressure (NIBP)
• Oxy-Cardiorespirography (Oxy-CRG)
• Oxygen Saturation (SPO2)
• S-T Segment & 72 hours trend data analysis
• Temperature
• Respiration
• Arrhythmia
• Drug Calculation
• Carbon Monoxide (CO2)
• Oxygen (O2)
• Nitrous Oxide (N2O)
• 5AA
• AA ID
